NVFM |
|
Processor |
Hi3516CV500 |
|
Display Screen |
7-inch high-definition screen |
|
Sensor |
SONY 1/2.8" CMOS |
|
Minimum Illumination |
0.01Lux@(F1.2,AGC ON) |
|
Shutter |
1/25 second to 1/10000 second |
|
Lens |
6mm fixed focus |
|
Day and Night Parameters |
Adaptive |
|
WDR |
Support |
|
Digital Noise Reduction |
Automatic adjustment |
|
BLC |
Support |
|
Voice Broadcast |
Support, support TTS voice broadcast customization; |
|
Video Standard |
H.264 |
|
Code Rate |
1024Kbps~4Mbps |
|
Encoding Format |
H.264 |
|
Video Size |
720P（1280*720） |
|
Frame Rate |
25fps |
|
Video Overlay |
Time, point name |
|
Video Settings |
Exposure (shutter), AGC, contrast, saturation, brightness adjustable, face exposure compensation |
|
Image Format |
Use JPEG encoding |
|
Snapshot Result |
Panoramic view, partial close-up view |
|
Size of the Picture |
1920*1080, partial close-up pictures are based on the actual picture ratio |
|
Recognition Pattern |
Offline dynamic face recognition |
|
Identification Type |
1：N |
|
Live Detection |
|
|
Face Library |
50000 |
|
Pass Record |
Characteristic value: 100,000 Panorama picture + feature picture: 30,000 |
|
Recognition Speed |
≤200ms |
|
Recognition Distance |
0.5-2m |
|
Portrait Library Issued |
Single picture, batch picture, real-time snapshot picture import, platform release |
|
Management Type |
Blacklist, whitelist, temporary users |
|
Output Mode |
Wiegand 26/34/66, relay |
|
Trigger Method |
Video trigger |
|
Supported Protocol |
ONVIF,GB28181,TCP/IP,HTTP,DNS,NTP,FTP,RS485 protocol, Wiegand protocol |
|
General Function |
Heartbeat, password protection, NTP |
|
Communication Interface |
1 RJ45 10M/100M adaptive Ethernet port |
|
Relay Interface |
1 relay output |
|
Wiegand Interface |
1 Wiegand input 1 Wiegand output |
|
USB Interface |
1 channel |
|
RS485 Interface |
1 channel |
|
Power Supply |
DC 12V/2A |
|
Power Consumption |
≤10W |
|
Working Temperature |
-20℃～＋70℃ |
|
Working Humidity |
0%－90% |
|
Size |
|
|
Weight |
1.63kg |
|
List of Accessories |
Host machine, power supply, manual, certificate, hexagonal tools |
|
Package Size |
380mm*165mm*110mm |
|
Package Weight |
2.1kg |
|
