NVJ51_(M)F |
|
Model |
NVJ515MF |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
5 Megapixel |
|
Electronic Shutter |
AUTO |
|
Min. Illumination |
0.001Lux@F1.2(AGC ON) |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto |
|
AGC/BLC/HLC |
Support |
|
DNR |
2D/3D DNR |
|
Other Camera Parameter |
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip |
|
Video Standard |
H.265/H.264 |
|
Video Resolution |
MainStream:25fps30fps@5MP(2592x1944),25fps30fps@4MP/3MP, 30fps@1080P/720P Sub stream: D1/VGA(640x480)/360P/QVGA@25fps |
|
Video Bitrates |
32Kbps - 8Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
IR Led |
2 pcs 28mil Array IR Leds |
|
IR Distance |
10-20 M |
|
Smart IR |
Support (IR on illumination level adjustable) |
|
Lens Focal length |
3.6mm Fixed lens |
|
Optional Function |
Auido,SD card slot |
|
Protocol |
HTTP/RTSP/FTP/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox (32bit esr), etc. |
|
Network Services Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 5 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
