NVJ518F

  • 8 Megapixel

    HD 3.6 mm fixed lens (2.8mm optional)

    ●MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.  Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.

NVJ51_(M)F
Model NVJ518F
Image Sensor 1/2.8" CMOS Sensor
Effective Pixels 8 Megapixel
Electronic Shutter AUTO
Min. Illumination 0.001Lux@F1.2(AGC ON)
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto
AGC/BLC/HLC Support
DNR 2D/3D DNR
Other Camera Parameter Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip
Video Standard H.265/H.264
Video Resolution MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc. Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.
Video Bitrates 32Kbps - 8Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
IR Led 2 pcs 28mil Array IR Leds
IR Distance 10-20 M
Smart IR Support (IR on illumination level adjustable)
Lens Focal length 3.6mm Fixed lens
Optional Function Auido,SD card slot
Protocol HTTP/RTSP/FTP/SMTP/DHCP/NTP, etc.
P2P Yes
Web IE , Firefox (32bit esr), etc.
Network Services Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE optional
Power Supply 12 VDC ± 10%
Power Consumption < 5 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
