NVJ56_(M)F-Z4X |
|
Model |
NVJ565MF-Z4X |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
5 Megapixel |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
BLC /HLC |
Support |
|
DNR |
2D/3D DNR |
|
Other Camera Parameter |
AGC,Motion Detection,Privacy Mask,Flip,Rotate,RIO,OSD overlay |
|
Embedded Solution |
Mstar328Q |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
MainStream:25fps30fps@5MP(2592x1944),25fps30fps@4MP/3MP, 30fps@1080P/720P Sub stream: D1/VGA(640x480)/360P/QVGA@25fps |
|
Video Bitrates |
512Kbps - 12Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
OSD Overlay |
Title and Time overlay ,custom color adjustable |
|
IR Led |
4 pcs Hi-power Array IR Leds |
|
IR Distance |
70-80 M |
|
Lens Focal length |
2.8 -12 mm AF lens |
|
Lens Zoom |
4x optical zoom |
|
Optional Function |
POE, Audio, etc. |
|
Protocol |
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP/NFS, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox 32bit ESR |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 10 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
