NVJ568F-Z4X

  • ●8 Megapixel
    2.8 -12 mm AF lens
    MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.  Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.
NVJ56_(M)F-Z4X
Model NVJ568F-Z4X
Image Sensor 1/2.8" CMOS Sensor
Effective Pixels 8 Megapixel
Electronic Shutter AUTO, 1/25s ~ 1/100000s
Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Manual
BLC /HLC Support
DNR 2D/3D DNR
Other Camera Parameter AGC,Motion Detection,Privacy Mask,Flip,Rotate,RIO,OSD overlay
Embedded Solution Mstar328Q
Video Standard H.264/H.265
Video Resolution MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc. Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.
Video Bitrates 512Kbps - 12Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
OSD Overlay Title and Time overlay ,custom color adjustable
IR Led 4 pcs Hi-power Array IR Leds
IR Distance 70-80 M
Lens Focal length 2.8 -12 mm AF lens
Lens Zoom 4x optical zoom
Optional Function POE, Audio, etc.
Protocol HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP/NFS, etc.
P2P Yes
Web IE , Firefox 32bit ESR
Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE optional
Power Supply 12 VDC ± 10%
Power Consumption < 10 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
