NVJ565MF-Z10X

  • ● 5 Megapixel

    ● 5-50mm Motorized lens

    ● MainStream:25fps30fps@5MP(2592x1944),25fps30fps@4MP/3MP,30fps@1080P/720P

    Substream:D1/VGA(640x480)/360P/QVGA@25fps



NVJ56_(M)F-Z10X
Model NVJ565MF-Z10X
Image Sensor 1/2.8" CMOS Sensor
Effective Pixels 2592(H)×1944 (V)
Electronic Shutter AUTO, 1/25s ~ 1/100000s
Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Manual
BLC Support
DNR 2D/3D DNR
Other Camera Parameter Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Rotate
Embedded Solution Mstar328Q
Video Standard H.264/H.265
Video Resolution MainStream:25fps30fps@5MP(2592x1944),25fps30fps@4MP/3MP, 30fps@1080P/720P Sub stream: D1/VGA(640x480)/360P/QVGA@25fps
Video Bitrates 32Kbps - 8Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a/AAC
OSD Overlay Title and Time overlay
IR Led 4 pcs array IR Leds
IR Distance 80 M
Lens Focal Length 5-50mm Motorized lens
Zoom /
Optional Function POE, Audio, etc.
Protocol HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
P2P Yes
Web IE , Firefox, etc.
Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE optional
Power Supply 12 VDC ± 10%
Power Consumption < 8 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
