NVJ56_(M)F-Z10X |
|
Model |
NVJ568F-Z10X |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
8 Megapixel |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
BLC |
Support |
|
DNR |
2D/3D DNR |
|
Other Camera Parameter |
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Rotate |
|
Embedded Solution |
Mstar 328Q |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc. Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc. |
|
Video Bitrates |
32Kbps - 8Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a/AAC |
|
OSD Overlay |
Title and Time overlay |
|
IR Led |
4 pcs array IR Leds |
|
IR Distance |
80 M |
|
Lens Focal Length |
5-50mm Motorized lens |
|
Zoom |
/ |
|
Optional Function |
POE, Audio, etc. |
|
Protocol |
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 8 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
