NVJ55_(M)F-WL |
|
Model |
NVJ552MF-WL |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
2 Megapixel |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.001Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Indoor/Outdoor |
|
BLC |
Support |
|
DNR |
2D/3D DNR |
|
Other Camera Parameter |
Motion Detection, Privacy Mask, Mirror, flip |
|
Embedded Solution |
Mstar 328Q |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
Main Stream:30fps@1080P/720P Sub Stream: VGA(640x480)/360P/QVGA@30fps, etc. |
|
Video Bitrates |
512Kbps - 12Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
OSD Overlay |
Title and Time overlay |
|
Leds |
4PCS Soft & Warm Supplemental Light |
|
Light Distance |
30-40 M |
|
Lens Focal Length |
HD 3.6mm F1.0 true starlight lens |
|
Optional Functions |
Audio/SD card slot (support maximum 256GB SD card ) |
|
Protocol |
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE |
|
Power Supply |
IEEE802.3af PoE, 12 VDC ± 10% |
|
Power Consumption |
< 8 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
