NVJ555F-WL

  • ● 5 Megapixel

    ● F1.0 3.6mm

    ● Main Stream:15fps@5MP(2592x1944),25fps@4MP/3MP,30fps@1080P/720P

    Sub Stream: D1/VGA(640x480)/360P/QVGA@25fps


NVJ55_(M)F-WL
Model NVJ555F-WL
Image Sensor 1/2.8" CMOS Sensor
Effective Pixels 5 Megapixel
Electronic Shutter AUTO, 1/25s ~ 1/100000s
Min. Illumination 0.001Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Indoor/Outdoor
BLC Support
DNR 2D/3D DNR
Other Camera Parameter Motion Detection, Privacy Mask, Mirror, flip
Embedded Solution Mstar 328Q
Video Standard H.264/H.265
Video Resolution Main Stream: 15fps@5MP(2592x1944),25fps@4MP/3MP,30fps@1080P/720P Sub Stream: D1/VGA(640x480)/360P/QVGA@25fps
Video Bitrates 512Kbps - 12Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
OSD Overlay Title and Time overlay
Leds 4PCS Soft & Warm Supplemental Light
Light Distance 30-40 M
Lens Focal Length HD 3.6mm F1.0 true starlight lens
Optional Functions Audio/SD card slot (support maximum 256GB SD card )
Protocol HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
P2P Yes
Web IE , Firefox, etc.
Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE
Power Supply IEEE802.3af PoE, 12 VDC ± 10%
Power Consumption < 8 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
