NVJ502MF

  • 2 Megapixel

    3.6mm fix lens

    ● Main Stream:30fps@1080P/720P

    Sub Stream: VGA(640x480)/360P/QVGA@30fps, etc.



NVJ50_(M)F
Model NVJ502MF
Image Sensor 1/2.8" CMOS Sensor,
Effective Pixels 2 Megapixel
Electronic Shutter AUTO, 1/25s ~ 1/100000s
Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Indoor/Outdoor
BLC Support
DNR 2D/3D DNR
Other Camera Parameter Motion Detection, Privacy Mask, Mirror, flip
Embedded Solution Mstar 325
Video Standard H.264/H.265
Video Resolution Main Stream:30fps@1080P/720P Sub Stream: VGA(640x480)/360P/QVGA@30fps, etc.
Video Bitrates 32Kbps - 8Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
OSD Overlay Title and Time overlay
IR Led 12 pcs SMD array Leds
IR Distance 20 M
Lens Focal Length 3.6mm fix lens
Optional Function Audio, etc.
Protocol HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
P2P Yes
Web IE , Firefox, etc.
Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE
Power Supply 12 VDC ± 10%
Power Consumption < 8 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
