NVJ565MAFS-VF4X

  • ●5 Megapixel

    ●HD 2.8-12 mm varifocal lens

    ●Main Stream:30fps@ 5MP(2592*1944) , 30fps@ 4MP(2592*1520) Sub Stream: D1/VGA(640x480)/360P/QVGA@30fps

NVJ565MAFS-VF4X Series
Image Sensor 1/2.8" SONY IMX335 CMOS
Effective Pixels 2592 (H) × 1944 (V)
Electronic Shutter AUTO, 1/25s ~ 1/100000s
Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Indoor/Outdoor
BLC Support
DNR 2D/3D DNR
Other Motion Detection, Privacy Mask, Mirror, flip
Embedded Solution Mstar 328Q
Video Standard H.264/H.265
Video Resolution Main Stream:30fps@ 5MP(2592*1944) , 30fps@ 4MP(2592*1520) Sub Stream: D1/VGA(640x480)/360P/QVGA@30fps
Video Bitrates 32Kbps - 8Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a
OSD Overlay Title and Time overlay
IR Led 4pcs array Leds
IR Distance 80 M
Focal length HD 2.8-12 mm varifocal lens
Audio 1 RCA in (sound pick-up), 1 RCA out (talk-back)
Alarm 1 Alarm in (switch), 1 Alarm out (+12VDC)
Storage Micro-SD slot (Max. 128GB )
RS-485 Yes
POE Internal POE
Protocol HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
P2P Yes
Web IE , Firefox, etc.
Media CMS, Android, IOS
ONVIF 17.06 compatible
Network Port 1-RJ45, 100Mbps, POE
Power Supply 12 VDC ± 10%
Power Consumption < 8 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH
