NVJ565MAFS-VF4X Series |
|
Image Sensor |
1/2.8" CMOS Sensor |
|
Effective Pixels |
5 Megapixel |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Indoor/Outdoor |
|
BLC |
Support |
|
DNR |
2D/3D DNR |
|
Other |
Motion Detection, Privacy Mask, Mirror, flip |
|
Embedded Solution |
MC316DM |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
Main Stream: 25fps@5MP(2592x1944)/4MP(2592x1520)/3MP, 30fps@1080P/720P Sub stream: 25fps@D1/VGA/360P/CIF, etc. |
|
Video Bitrates |
32Kbps - 8Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
OSD Overlay |
Title and Time overlay |
|
IR Led |
4pcs array Leds |
|
IR Distance |
80 M |
|
Focal length |
HD 2.8-12 mm varifocal lens |
|
Audio |
1 RCA in (sound pick-up), 1 RCA out (talk-back) |
|
Alarm |
1 Alarm in (switch), 1 Alarm out (+12VDC) |
|
Storage |
Micro-SD slot (Max. 128GB ) |
|
RS-485 |
Yes |
|
POE |
Internal POE |
|
Protocol |
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
Network Port |
1-RJ45, 100Mbps, POE |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 8 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
|
