NVSS8X04 Series |
|
Model |
NVSS8704 |
|
Main Processor |
Intel core i7 CPU |
|
Operating System |
64bit Linux OS |
|
Memory |
16GB |
|
Bandwidth |
512Mbps |
|
Recording |
256ch@8MP / 4MP / 1080P |
|
Preview |
12ch@8MP(4K) or 16ch@5M or 25ch@4M/3M or 49ch@1080P or 81ch@720P or 144ch@D1 |
|
Playback |
12ch@8MP(4K) or 16ch@5M/4M/3M/1080P/720P |
|
Audio |
1ch audio & 1ch Mic in, 1ch audio out |
|
Recording Mode |
Manual, Schedule(Continuous, Motion detection, Sensor Alarm), Stop |
|
Alarm Recording |
Motion detection, External alarm |
|
Backup Mode |
Network download / USB HDD / Mobile DVD |
|
Video Output |
VGA+HDMI output, HDMI support 4K output |
|
Display split |
Main:1/4/6/9/13/16/20/25/28/33/36/40/49/64/81/100/121/144 split, sub:1/4/6/9/13/16 split. |
|
HDMI/VGA Output |
3840*2160(HDMI) / 1920*1080 / 1680*1050 / 1440*900 / 1280*1024 / 1024*768 |
|
Interface |
2 RJ-45 ports(1000M) |
|
Power Supply |
Max. 300W (Include HDD) |
|
Hard Disk |
4 SATA, Max.10TB for each; Independent HDD rack, support hot swap, RAID storage |
|
USB |
6 USB ports |
|
Work Environment |
Temperature: 0˚C~60˚C; Humidity: 10%~80% ( non-condensation) |
|
Dimension |
420×440mm×88mm (W×D×H); 2U case |
